Máy chủ Dell PowerEdge R660xs/ 8x2.5"/ Intel Xeon Silver 4510 2.4G/ 16GB RDIMM/ 1.2TB SAS/ PERC H755/ iDRAC9 Ent/ 2 x 800W/ ProSupport 3Y

Base PowerEdge R740XD Server
Chassis Configuration Chassis with up to 24 x 2.5" SAS/SATA Hard Drives for 1CPU Configuration
Processor Intel® Xeon® Silver 4210R 2.4G, 10C/20T, 9.6GT/s, 13.75M Cache, Turbo, HT (100W) DDR4-2400
Memory Capacity 16GB RDIMM, 3200MT/s, Dual Rank
RAID/Internal Storage Controllers PERC H730P RAID Controller, 2Gb NV Cache, Minicard
Hard Drives 1.2TB 10K RPM SAS 12Gbps 512n 2.5in Hot-plug Hard Drive
Embedded Systems Management iDRAC9,Enterprise
Network Daughter Card Broadcom 5720 Quad Port 1GbE BASE-T, rNDC
Power Supply Dual, Hot-plug, Redundant Power Supply (1+1), 750W
Bezel PowerEdge 2U Standard Bezel (Dell EMC)
Dell Services: Extended Service ProSupport and Next Business Day Onsite Service-ACDTS, 48 Month(s)
Rack Rails ReadyRails™ Sliding Rails With Cable Management Arm
Internal Optical Drive No Internal Optical Drive for 24 HD Chassis

Base PowerEdge R740XD Server
Chassis Configuration Chassis with up to 12 x 3.5" SAS/SATA Hard Drives for 1CPU Configuration
Processor Intel® Xeon® Silver 4210R 2.4G, 10C/20T, 9.6GT/s, 13.75M Cache, Turbo, HT (100W) DDR4-2400
Memory Capacity 16GB RDIMM, 3200MT/s, Dual Rank
RAID/Internal Storage Controllers PERC H730P RAID Controller, 2Gb NV Cache, Minicard
Hard Drives 4TB 7.2K RPM NLSAS 12Gbps 512n 3.5in Hot-plug Hard Drive
Embedded Systems Management iDRAC9,Enterprise
Network Daughter Card Broadcom 5720 Quad Port 1GbE BASE-T, rNDC
Power Supply Dual, Hot-plug, Redundant Power Supply (1+1), 750W
Bezel PowerEdge 2U Standard Bezel (Dell EMC)
Dell Services: Extended Service ProSupport and Next Business Day Onsite Service-ACDTS, 48 Month(s)
Rack Rails ReadyRails™ Sliding Rails With Cable Management Arm
Internal Optical Drive No Internal Optical Drive for 12 HD Chassis

Base PowerEdge R740 Server
Chassis Configuration Chassis with up to 16x2.5" SAS/SATA Hard Drives for 1CPU Configuration
Processor Intel® Xeon® Silver 4214R 2.4G, 12C/24T, 9.6GT/s, 16.5M Cache, Turbo, HT (100W) DDR4-2400
Memory Capacity 16GB RDIMM, 3200MT/s, Dual Rank
RAID/Internal Storage Controllers PERC H730P RAID Controller, 2Gb NV Cache, Minicard
Hard Drives 1.2TB 10K RPM SAS 12Gbps 512n 2.5in Hot-plug Hard Drive
Embedded Systems Management iDRAC9,Enterprise
Network Daughter Card Broadcom 5720 Quad Port 1GbE BASE-T, rNDC
Power Supply Dual, Hot-plug, Redundant Power Supply (1+1), 750W
Bezel PowerEdge 2U Standard Bezel (Dell EMC)
Dell Services: Extended Service ProSupport and Next Business Day Onsite Service-ACDTS, 48 Month(s)
Rack Rails ReadyRails™ Sliding Rails With Cable Management Arm
Internal Optical Drive DVD+/-RW,SATA,Int

Base PowerEdge R740 Server
Chassis Configuration Chassis with up to 16 x 2.5" SAS/SATA Hard Drives for 1CPU Configuration
Processor Intel® Xeon® Silver 4210R 2.4G, 10C/20T, 9.6GT/s, 13.75M Cache, Turbo, HT (100W) DDR4-2400
Memory Capacity 16GB RDIMM, 3200MT/s, Dual Rank
RAID/Internal Storage Controllers PERC H730P RAID Controller, 2Gb NV Cache, Minicard
Hard Drives 1.2TB 10K RPM SAS 12Gbps 512n 2.5in Hot-plug Hard Drive
Embedded Systems Management iDRAC9,Enterprise
Network Daughter Card Broadcom 5720 Quad Port 1GbE BASE-T, rNDC
Power Supply Dual, Hot-plug, Redundant Power Supply (1+1), 750W
Bezel PowerEdge 2U Standard Bezel (Dell EMC)
Dell Services: Extended Service ProSupport and Next Business Day Onsite Service-ACDTS, 48 Month(s)
Rack Rails ReadyRails™ Sliding Rails With Cable Management Arm
Internal Optical Drive DVD+/-RW,SATA,Int

Base PowerEdge R640 Server
Chassis Configuration 2.5” Chassis with up to 8 Hard Drives and 3PCIe slots
Processor Intel® Xeon® Silver 4210R 2.4G, 10C/20T, 9.6GT/s, 13.75M Cache, Turbo, HT (100W) DDR4-2400
Memory Capacity 16GB RDIMM, 3200MT/s, Dual Rank
RAID/Internal Storage Controllers PERC H730P RAID Controller, 2GB NV Cache, Minicard
Hard Drives 1.2TB 10K RPM SAS 12Gbps 512n 2.5in Hot-plug Hard Drive
Embedded Systems Management iDRAC9,Enterprise
Network Daughter Card Broadcom 5720 Quad Port 1GbE BASE-T, rNDC
Power Supply Dual, Hot-plug, Redundant Power Supply (1+1), 750W
Bezel Standard Bezel for x4 and x8 chassis (Dell EMC)
Dell Services: Extended Service ProSupport and Next Business Day Onsite Service-ACDTS, 48 Month(s)
Rack Rails ReadyRails™ Sliding Rails With Cable Management Arm
Internal Optical Drive DVD +/-RW, SATA, Internal

Base PowerEdge R540 Server
Chassis Configuration 3.5" Chassis with up to 12 Hot Plug Hard Drives
Processor Intel® Xeon® Silver 4214R 2.4G, 12C/24T, 9.6GT/s, 16.5M Cache, Turbo, HT (100W) DDR4-2400
Memory Capacity 16GB RDIMM, 3200MT/s, Dual Rank
RAID/Internal Storage Controllers PERC H730P RAID Controller, 2GB NV Cache, Adapter, Low Profile
Hard Drives 4TB 7.2K RPM NLSAS 12Gbps 512n 3.5in Hot-plug Hard Drive
Embedded Systems Management iDRAC9,Enterprise
Additional Network Cards Dual-Port 1GbE On-Board LOM
Power Supply Single, Hot-plug, Power Supply (1+0), 750W
Bezel PowerEdge 2U Standard Bezel (Dell EMC)
Dell Services: Extended Service ProSupport and Next Business Day Onsite Service-ACDTS, 48 Month(s)
Rack Rails ReadyRails™ Sliding Rails With Cable Management Arm
Internal Optical Drive No Internal Optical Drive for 12 HD Chassis

Base PowerEdge R540 Server
Chassis Configuration 3.5" Chassis with up to 12 Hot Plug Hard Drives
Processor Intel® Xeon® Silver 4210R 2.4G, 10C/20T, 9.6GT/s, 13.75M Cache, Turbo, HT (100W) DDR4-2400
Memory Capacity 16GB RDIMM, 3200MT/s, Dual Rank
RAID/Internal Storage Controllers PERC H730P RAID Controller, 2GB NV Cache, Adapter, Low Profile
Hard Drives 2TB 7.2K RPM NLSAS 12Gbps 512n 3.5in Hot-Plug Hard Drive
Embedded Systems Management iDRAC9,Enterprise
Additional Network Cards Dual-Port 1GbE On-Board LOM
Power Supply Dual, Hot Plug, Redundant Power Supply (1+1), 750W
Bezel PowerEdge 2U Standard Bezel (Dell EMC)
Dell Services: Extended Service ProSupport and Next Business Day Onsite Service-ACDTS, 48 Month(s)
Rack Rails ReadyRails™ Sliding Rails With Cable Management Arm
Internal Optical Drive No Internal Optical Drive for 12 HD Chassis

Base PowerEdge R740 Server
Chassis Configuration Chassis with up to 8 x 2.5" SAS/SATA Hard Drives for 1CPU Configuration
Processor Intel® Xeon® Silver 4210R 2.4G, 10C/20T, 9.6GT/s, 13.75M Cache, Turbo, HT (100W) DDR4-2400
Memory Capacity 16GB RDIMM, 3200MT/s, Dual Rank
RAID/Internal Storage Controllers PERC H730P RAID Controller, 2Gb NV Cache, Minicard
Hard Drives 600GB 15K RPM SAS 12Gbps 512n 2.5in Hot-plug Hard Drive
Embedded Systems Management iDRAC9,Enterprise
Network Daughter Card Broadcom 5720 Quad Port 1GbE BASE-T, rNDC
Power Supply Dual, Hot-plug, Redundant Power Supply (1+1), 750W
Bezel PowerEdge 2U Standard Bezel (Dell EMC)
Dell Services: Extended Service ProSupport and Next Business Day Onsite Service-ACDTS, 48 Month(s)
Rack Rails ReadyRails™ Sliding Rails With Cable Management Arm
Internal Optical Drive DVD+/-RW,SATA,Int

Base PowerEdge R740 Server
Chassis Configuration Chassis with up to 8 x 2.5" SAS/SATA Hard Drives for 1CPU Configuration
Processor Intel® Xeon® Silver 4210R 2.4G, 10C/20T, 9.6GT/s, 13.75M Cache, Turbo, HT (100W) DDR4-2400
Memory Capacity 16GB RDIMM, 3200MT/s, Dual Rank
RAID/Internal Storage Controllers PERC H730P RAID Controller, 2Gb NV Cache, Minicard
Hard Drives 1.2TB 10K RPM SAS 12Gbps 512n 2.5in Hot-plug Hard Drive
Embedded Systems Management iDRAC9,Enterprise
Network Daughter Card Broadcom 5720 Quad Port 1GbE BASE-T, rNDC
Power Supply Dual, Hot-plug, Redundant Power Supply (1+1), 750W
Bezel PowerEdge 2U Standard Bezel (Dell EMC)
Dell Services: Extended Service ProSupport and Next Business Day Onsite Service-ACDTS, 48 Month(s)
Rack Rails ReadyRails™ Sliding Rails With Cable Management Arm
Internal Optical Drive DVD+/-RW,SATA,Int

Base PowerEdge R740 Server
Chassis Configuration Chassis with up to 8 x 2.5" SAS/SATA Hard Drives for 1CPU Configuration
Processor Intel® Xeon® Silver 4214R 2.4G, 12C/24T, 9.6GT/s, 16.5M Cache, Turbo, HT (100W) DDR4-2400
Memory Capacity 16GB RDIMM, 3200MT/s, Dual Rank
RAID/Internal Storage Controllers PERC H730P RAID Controller, 2Gb NV Cache, Minicard
Hard Drives 1.2TB 10K RPM SAS 12Gbps 512n 2.5in Hot-plug Hard Drive
Embedded Systems Management iDRAC9,Enterprise
Network Daughter Card Broadcom 5720 Quad Port 1GbE BASE-T, rNDC
Power Supply Dual, Hot-plug, Redundant Power Supply (1+1), 750W
Bezel PowerEdge 2U Standard Bezel (Dell EMC)
Dell Services: Extended Service ProSupport and Next Business Day Onsite Service-ACDTS, 48 Month(s)
Rack Rails ReadyRails™ Sliding Rails With Cable Management Arm
Internal Optical Drive DVD+/-RW,SATA,Int
